Schiess Vertimaster VMG 4 CNC Double Column Movable Columns Vertical Boring & Turning Machine

Year

2009

Stock Number

11019

Table diameter

4,000 mm

Swing

5,000 mm

Turning height

3,000 mm

Table capacity

50 Ton

Table turn speed

120 rpm

Gantry travel

5,000 mm

Dorries Scharmann Contumat 3 MC VC 4200/360 CNC Vertical Boring & Milling Machine with 2 Rams and Live Spindle Fully Rebuilt & Retrofitted. Mint Condition

Year

2015

Stock Number

5654230

Table diameter

4,000 mm

Swing

4,600 mm

Turning height

3,000 mm

Table capacity

80 Ton

Table turn speed

90 rpm

Crossrail travel

1,900 mm (in 100 mm steps)

Dorries Scharmann Contumat 3 MC: VC 4200/360 CNC Vertical Boring & Milling Machine with Vertical Ram & Live Spindle on Side Head, C -Axis Table with Y-Axis Movable Travel. Excellent Condition Not Used Much

Stock Number

5654233

Table diameter

3,600 mm

Swing

4,200 mm

Turning height

4,800 mm

Table capacity

80 Ton

Table turn speed

90 rpm

Y axis table travel

2,000 mm

Dorries Scharmann Contumat 3 MC: VC 4600/400 CNC Single Ram Vertical Turning Machine with Live Spindle Side Head Y-Axis Movable Table Travel

Stock Number

5654232

Table diameter

4,000 mm

Swing

4,200 mm

Turning height

4,800 mm

Table capacity

80 Ton

Table turn speed

90 rpm

Crossrail travel

3,700 mm (in 100 mm steps)

Schiess 40 DZ CNC Double Ram Vertical Boring & Milling Machine with Live Spindle & Table C-Axis

Stock Number

5654227

Table diameter

3,500 mm

Swing

4,000 mm

Turning height

3,000 mm

Table capacity

50 Ton

Table turn speed

100 rpm

Live spindle motor power

22.5 kW

Hwacheon HVT 4550M CNC Vertical Turning & Milling Machine with Live Spindle

Year

2015

Stock Number

5654229

Table diameter

4,500 mm

Swing

5,000 mm

Turning height

2,500 mm

Table capacity

40 Ton

X axis travel

-250 ~ +4,100 mm

Z axis travel

1,500 mm

Schiess 40 DZ CNC Single Ram Vertical Turning Machine with Live Spindle Side Head

Stock Number

5654228

Table diameter

4,000 mm

Swing

5,000 mm

Turning height

5,000 mm

Table capacity

80 Ton

Y axis table travel

2,500 mm

Crossrail travel

3,200 mm (in 50 mm steps)

Schiess 40DS 350/4000 – 250/160 CNC Double Column Vertical Turning & Boring Machine with Live Spindle & C-Axis

Stock Number

10582

Retrofit

1997

Table diameter

3,500 mm

Swing

4,000 mm

Turning height

2,500 mm

Table capacity

40 Ton

Table turn speed

90 rpm

Honor Seiki VL-400CM CNC Vertical Boring & Milling Machine with Live Spindle & Table C-Axis

Year

2018

Stock Number

11208

Table diameter

4,000 mm

Swing

4,500 mm

Turning height

3,000 mm

Table capacity

35 Ton

Table turn speed

85 rpm

Live spindle speed

2,250 rpm

Dorries VCE 2800/250 MC CNC Vertical Turning & Milling Machine with Live Spindle

Year

2010

Stock Number

5654222

Table diameter

2,500 mm

Swing

2,800 mm

Turning height

1,800 mm

Table capacity

25 Ton

Feed range

0 - 18,000 mm/min

Total power requirement

100 kW

TOS HULIN SKIQ 16 CNC Single Column Vertical Turning & Boring Machine with Live Spindle & C-Axis

Year

2025

Stock Number

11177

Table diameter

1,600 mm

Swing

1,800 mm

Turning height

1,275 mm

Table capacity

12 Ton

Table turn speed

200 rpm

Live spindle speed

3,300 mm

Hankook VTC 125E CNC Vertical Boring Machine with Live Spindle

Year

2015

Stock Number

11047

Table diameter

1,250 mm

Swing

1,600 mm

Turning height

1,400 mm

Table capacity

8 Ton

Table turn speed

360 rpm

Live spindle speed

3,000 rpm

Hankook VTC 200E CNC Double Column Vertical Boring & Turning Machine with Live Spindle

Year

2022

Stock Number

11041

Table diameter

2,000 mm

Swing

2,500 mm

Turning height

2,000 mm

Table capacity

12 Ton

Table turn speed

200 rpm

Live spindle speed

3,000 rpm

Hankook VLC 30/70 CNC Single Column Vertical Turning and Boring Machine with Live Spindle & Table C-Axis

Year

2016

Stock Number

11140

Table diameter

3,000 mm

Swing

7,000 mm

Turning height

3,000 mm

Table capacity

30 Ton

Table turn speed

80 rpm

X axis travel

2,225 mm

TOS HULIN SKQ 12 CNC Vertical Turning, Drilling, Milling, Grinding Machine

Year

2025

Stock Number

11229

Table diameter

1,250 mm

Swing

1,500 mm

Max workpiece height

900 mm

Max workpiece weight

6 Ton

Output power turning / milling

58 / 29 kW

Table speed

380 rpm

S&T ST 40/55VC CNC Vertical Boring & Milling Machine with Live Spindle & Table C-Axis

Year

2012

Stock Number

11216

Table diameter

4,000 mm

Swing

5,500 mm

Turning height

2,600 mm

Table capacity

45 Ton

Table turn speed

(2 step) 20/60 rpm

Live spindle speed

1,500 rpm

Pietro Carnaghi AC 20 TM-1800 Single Column CNC Vertical Boring & Milling Machine with Live Spindle Table C-Axis & 2 Pallet Changer

Year

2009

Stock Number

11083

Table diameter

1,800 mm

Swing

2,000 mm

Turning height

1,500 mm

Table capacity

5 Ton

Table turn speed

320 rpm

Live spindle speed

3,000 rpm

Toshiba TMD 16 CNC Vertical Boring & Milling Machine with Live Spindle and Automatic Pallet Changer

Stock Number

11210

Table diameter

1,600 mm

Swing

2,000 mm

Turning height

1,400 mm

Table capacity on machine

10,000 kg

Table capacity on APC

5,000 kg

Table turn speed (2 ranges)

280 rpm

Schiess VMG CNC Vertical Boring & Milling Machine with Live Spindle & Travelling Gantry Y-Axis

Year

2006

Stock Number

11185

Table diameter

2,800 mm

Swing

3,200 mm

Max machining height

2,500 mm

Table capacity

25 Ton

Table speed for turning

0.62 - 210 rpm

Table speed for milling

0.0004 - 4 rpm

Giddings & Lewis VTC 1600 CNC Vertical Boring & Milling Machine with Live Spindle & Table C-Axis

Year

2023

Stock Number

11165

Table diameter

1,600 mm

Swing

2,000 mm

Turning height

1,930 mm

Z axis ram travel

1,750 mm

Live spindle speed

4,000 rpm

Table turn speed

400 rpm

Doosan VTS 1620M CNC Vertical Turning & Boring Machine with Live Spindle and C-Axis

Year

2014

Stock Number

11182

Table diameter

1,600 mm

Swing

2,000 mm

Turning height

1,556 mm

Table capacity

10 Ton

Table turn speed

250 rpm

Live spindle speed

3,000 rpm

Dorries VCE 200/140 CNC Single Column Vertical Turning & Boring Machine with Live Spindle & Table C-Axis

Year

1987

Stock Number

11173

Table diameter

1,400 mm

Swing

2,000 mm

Turning height

1,270 mm

Table capacity

6,000 kg

Table turn speed

355 rpm

Live spindle speed

3,000 rpm

CAMU – AEPI 10MT CNC SINGLE COLUMN VERTICAL TURNING & BORING MACHINE with Y-AXIS MOVABLE COLUMN (2) RAMS with Live Spindle & Table C Axis

Year

2014

Stock Number

11150

Table diameter

3,400 mm

Swing

10,000 mm

Turning height

5,000 mm

Table capacity

50 Ton

Table turn speed

30 rpm

Dimensions, machine only

12,800 x 5,800 x 8,000 mm

Okuma VTM 200 CNC Vertical Turning & Boring Machine with Live Spindle & Table C-Axis

Year

2012

Stock Number

11135

Table diameter

2,000 mm

Swing

2,400 mm

Turning height

1,200 mm

Table capacity

7 Ton

Table turn speed

200 rpm

Live spindle speed

4,500 rpm

HNK VTC 50/85 CNC Heavy Duty Double Column Vertical Boring & Turning Machine with Live Spindle & Table C-Axis

Year

2013

Stock Number

10248

Table diameter

5,000 mm

Swing

8,500 mm

Turning height

5,000 mm

Table capacity

60 Ton

Table turn speed

50 rpm

Live milling spindle speed

1,000 rpm

Pietro Carnaghi AC 62 CNC Vertical Boring & Milling Machine with Live Spindle & Table C-Axis

Year

2010

Stock Number

11055

Table diameter

5,000 mm

Swing

6,200 mm

Turning height

5,000 mm

Table capacity

100 Ton

Table turn speed

76 rpm

Live spindle speed

2,500 rpm

Hankook VTC 140E CNC Ram Type Vertical Boring & Milling Machine with Live Spindle & Table C-Axis

Year

2014

Stock Number

11076

Table diameter

1,400 mm

Swing

1,600 mm

Turning height

1,400 mm

Table capacity

8 Ton

Table turn speed

360 rpm (Auto 2 step)

Live spindle speed

3,000 rpm

ACME Double Ram CNC Vertical Boring & Milling Machine with Live Spindle & Table C-Axis

Year

2023

Stock Number

11070

Table diameter

4,500 mm

Swing

5,600 mm

Turning height

4,000 mm

Table capacity

60 Ton

Table turn speed

40 rpm

Live spindle speed

1,200 rpm

Mario Carnaghi TGP 25/3000 HDD CNC Vertical Boring & Milling Machine with Travelling Table

Year

2023

Stock Number

11038

Table diameter

2,500 mm

Swing

3,000 mm

Turning height

2,000 mm

Table capacity

35 Ton

Table turn speed

180 rpm

Live spindle speed

4,000 rpm

Miba MCRT 14 CNC Vertical Boring & Milling Machine with Live Spindle

Year

2017

Stock Number

11037

Table diameter

13,000 mm

Turning height

4,000 mm

Table capacity

50 Ton

Table turn speed

40 rpm

Live spindle speed

3,000 rpm

Z axis travel

4,000 mm

UNISIGN UNICOM 6000 CNC VERTICAL TURNING & MILLING CENTER with AUTOMATIC PALLERT CHANGER for 3 PALLETS

Year

2008

Stock Number

10763

Table diameter

1,800 mm

Swing

2,000 mm

Turning height

1,200 mm

Table turn speed

300 rpm

Live spindle speed

6,000 rpm

Z axis travel

1,000 mm

Homma HMT-8/10 GTN CNC Heavy Duty Gantry Type Double Column Milling Machine / Vertical Turning Mill

Year

2011

Stock Number

10913

Table diameter

8,000 mm

Swing

10,000 mm

Turning height

7,200 mm

Table capacity

250 Ton

Live spindle speed

1,600 rpm

Gantry travel

15,000 mm

Morando KR 50/65 CNC Double Column Vertical Boring Machine

Stock Number

10939

Table diameter

4,000 mm

Swing

6,500 mm

Turning height

4,000 mm

Table capacity

100 Ton

Table turn speed

60 rpm

Live spindle speed

0 - 2,000 rpm

HNK VTC 50/70 CNC Heavy Duty Double Column Vertical Boring & Turning Machine with Live Spindle

Year

2012

Stock Number

10342

Table diameter

5,000 mm

Swing

7,000 mm

Turning height

5,000 mm

Table capacity

60 Ton

Table turn speed

50 rpm

Live spindle speed

1,000 rpm
