FKD KHF 460 CNC Crankshaft Lathe
FKD KHF 460 CNC Crankshaft Lathe
or
Call 770-509-0744
Specifications
| Manufacturer | FKD |
| Model | KHF 460 |
| Condition | New |
| Stock Number | 5654213 |
| Faceplate diameter | 3,000 mm |
| Weight of workpiece | 12 Ton |
| Length adjustment | 2,000 mm |
| Rapid traverse | 10,000 mm/min |
| Stepless feed | 0 - 5,000 mm/min |
| Max torque faceplate | 50000 Nm |
| Speed continuously adjustable | 0 - 80 rpm |
| Diameter of milling cutter | 4,600 mm |
| Depth of milling groove | 1,300 mm |
| Axial adjustment of milling machine | 320 mm |
| Axial positioning speed milling spindle | 0.5 - 140 mm/min |
| Milling cutter positioning | 0.1° |
| Speed infinitely adjustable | 0.0 - 10 rpm |
| Max torque on cutter | 315000 Nm |
