Waldrich Siegen DH 1600/35 x 12000 CNC Turbine Shaft / Roll Lathe
Waldrich Siegen DH 1600/35 x 12000 CNC Turbine Shaft / Roll Lathe
or
Call 770-509-0744
Description
NEW Siemens CNC Control System
Specifications
| Manufacturer | Waldrich Siegen |
| Model | DH 1600/35 x 12000 |
| Condition | Used |
| Stock Number | 10733 |
| Retrofit | 2021 |
| Between centers | 12,000 mm |
| Capacity between centers | 35 Ton |
| Swing over slide | 1,600 mm |
| Chuck diameter | 1,200 mm |
| Tailstock diameter | 360 mm |
| Power at main spindle/headstock | 136 kW |
| Chuck speed | 1 - 240 rpm |
| Step 1 | 1 - 60 rpm |
| Step 2 | 4 - 240 rpm |
| Base speed | 15 rpm |
| Max work piece length | 11,800 mm |
| Clamping area outside, min - max | 105 - 1,000 mm |
| Number of clamping jaws | No. 4 |
| Max torque at face plate | 80,000 Nm |
| Center angle | 60 Degree |
| No. of carriages | No. 1 |
| Travel way - z axis | 13,500 mm |
| Travel way - x axis | 700 mm |
| Traverse x axis | 0 - 4,500 mm/min |
| Traverse z axis | 0 - 4,500 mm/min |
| Rapid traverse x, z axes | 4,500 mm/min |
| Clamping area | 125 - 650 mm |
| Movement of quill | 100 mm |
| No. of steadies | 2 |
| Number of quills | No. 3 |
| Rapid traverse | 2,150 mm/min |
| Machine length | 20,000 mm |
| Machine width | 5,000 mm |
| Machine height, above floor level | 2,400 mm |
| Machine weight | 105 Ton |
