SHW UniForce 6X CNC Travelling Column Milling Machine
SHW UniForce 6X CNC Travelling Column Milling Machine
or
Call 770-509-0744
Description
Year of construction 2005
• 2016: General overhaul of headstock unit
• 2022: General overhaul of milling head
Heidenhain iTNC 530 CNC Control
Universal milling head in orthogonal design:
- Swivel range of milling head holder: 360 x 1°
- Swivel range of milling head: 180 x 1°
- Tool holder: SK 50 DIN 69871
- Speed: 3,200 rpm
Chip conveyor:
- Discharge height above floor: 1,250 mm
- Feed length: 8,000 mm
- Feed width: 350 mm
Coolant device:
- Paper belt filter system
- Tank capacity: 800 L
- Pumping capacity on the machine 16 bar
- approx. 32 l/min
Specifications
| Manufacturer | SHW |
| Model | UniForce 6X |
| Year | 2005 |
| Condition | Used |
| Stock Number | 5654303 |
| Spindle speeds | 3,200 rpm |
| X axis travel | 8,000 mm |
| Y axis travel | 2,600 mm |
| Z axis travel | 1,600 mm |
| Swivel range | 360° |
| Feed speed x | 20 m/min |
| Feed speed y/z | 24 m/min |
| Rapid feeds x | 20 m/min |
| Rapid feeds y/z | 24 m/min |
